POWERWIN MT30 MPPT Solar Charge Controller
Model Number: POWERWIN MT01
Maximum Current: 30A
is_customized: Yes
Certification: CE
Certification: FCC
Certification: RoHS
Is Smart Device: No
Application: Voltage Controller
Application: Solar System Controller
Supporting battery voltage: 12V or 24V
Dual USB 30A MPPT Solar Charge Controller;
Compatibility 12V and 24V System;
Using innovative MPPT technology high tracking efficiency up to 99%;
Compared with normal solar charge controller, increase efficiency by 10%-30%.
MULTIPLE INTELLIGENT PROTECTION:
Built-in Overcurrent Protection;
Short Circuit Protection;
Reverse Connection Protection;
Open Circuit Protection;
All Automatic Recovery, No Damage To The Controller, A Reliable Protector For Your Devices.
To Protect The Lifespan Of Your Battery, Once The Voltage Of The Battery Drops Below 11.5V, The Solar Controller Will Turn Off Automatically.
FUNCTIONAL LCD SCREEN:
Easy To Install And Operate;
LCD Display :Clearly Indicate The Status / Switch Modes And Parameter Configuration;
The Level Of Complete Power-Off Is Adjustable;
Perfectly Protect The Lithium Battery From Over-Discharge;
Suitable For Home, Industrial, Commercial Etc.
INDUSTRIAL-GRADE MASTER CHIP:
Sampling Accuracy;
Temperature Charging Current;
Discharge Current Accurate Real-Time Display;
Power Generation At A Glance.
Batt Voltage:12V/24V Auto
Charge Current:30A
Discharge Current:10A
Max Solar Input:12V Battery ,The Highest 23V;24V Battery ,The Highest 46V
Equailzation:14.4V
Float Charge:13.7V(Defaul,Adjustable)
Discharge Stop:10.7V(Defaul,Adjustable)
Discharge Reconnect:13.7V(Defaul,Adjustable)
Voltage Of Open Light: Solar Panel 8V (Light Lights Delay)
Voltage Of Close Light: Solar Panel 8V (Light Off Delay)
Use Output:2 Way USB Output,5V/2.5A(Max)
Self-consume:<10mA
Working Temperature:-35-+60
Size/Weight:170*98*45MM/450G
